SD64 4x4x4 | Self Drive Work Platform
Working Height
21.3m 70ft
Platform Height
19.3m 63ft 6in
Working Outreach
12.8m 42ft
Safe Working Load
225kg 500lbs500lbs
Minimum Weight
3950kg 8700lbs9170lbs
The SD64 4x4x4 work platform is the ultimate combination of our tow-behind and self-propelled product ranges.
With fully independent suspension and 4 wheel drive, the SD64 4x4x4 work platform can cope with a wide range of working environments and still offers the same impressive reach as the SP64.
Low weight design makes the SD64 4x4x4 work platform economical and quick to transport and 4 wheel steer gives the user enormous flexibility to maneuver once on site.
Excellent gradeability coupled with a good travel speed allow the SD64 4x4x4 work platform to be positioned and set up quickly, allowing the user to spend more of their time working.
The extra maneuverability available from the 4 wheel steer option coupled with the special "Turf Tires" make the SD64 4x4x4 work platform ideal for working on sensitive surfaces such as grass.
For more information regarding the SD64 4x4x4 or any other Self Drive work platform, including the SD50 4x4, please go to our inquire now page.
SD64 4x4x4 Features
4 Wheel Drive
Maximum traction over rough terrain
4 Wheel Steer
Superior maneuverability on site
Independent Suspension
For fast comfortable positioning on site
Platform Rotation & Jib
Improved access to applications
Turf Tires
For minimal disruption to sensitive grass surfaces
SD64 4x4x4 Specifications
Working Height (A)
21.3m 70ft
Working Outreach (C)
12.8m 42ft
Platform Height (B)
19.3m 63ft 6in
Machine Width (F)
2.05m 6ft 9in
Machine Height (D)
2.25m 7ft 5in
Machine Length (J)
6.15m 20ft 2in
Working Width (G)
4.2m 13ft 9in
Travel Speed
9km/h 5.6mph
Gradeability
45% / 24°
Turning Radius
3.5m 11ft 6in
Minimum Weight
3950kg 8700lbs 9170lbs
Safe Working Load
225kg 500lbs 500lbs
Jib Boom Arc
150°
Basket Rotation
100°
Basket Width
1.8m 5ft 11in
Basket Depth
0.85m 2ft 9in
Maximum Slope
18% / 10°
SD64 4x4x4 Diagram
